CS-X5S-R100-4W

  • Centerpiece Wireless Hub: Manages and stores footage for up to 4 Wi-Fi or Wired IP cameras

  • Crystal-Clear 3K (5MP) Support: Handles ultra-high-definition live views and history playback

  • Wall-Penetrating Wi-Fi Range: Dual external antennas deliver up to 100m stable wireless coverage

  • Efficient H.265 Video Technology: Compresses video sizes by 50% to save storage and bandwidth

  • Massive 8TB Storage Capacity: Single SATA slot supports standard 3.5″ hard drives up to 8TB

  • Flexible Dual Video Outputs: Connects easily to monitors via simultaneous HDMI and VGA ports

  • Universal ONVIF Compatibility: Smoothly syncs with both EZVIZ and ONVIF-conformant cameras

  • Dedicated 24/7 Local Security: Ensures non-stop, secure video logging independent of cloud dependencies

SKU: EZV00011 Brand:

රු12,290.00

17 People watching this product now!
  • Pick up from the Micro CCTV Stores

To pick up today

Free

  • Courier delivery

Our courier will deliver to the specified address

2-3 Days

Delivery charges will vary based on the total weight of the items.

  • Transport

Inform us of your preferred transport method to arrange the delivery.

Next Day

Free

  • Warranty 2 years

Payment Methods:

Description

The EZVIZ CS-X5S-R100-4W is a professional-grade, high-capacity Wireless Network Video Recorder (NVR) designed to serve as the centralized storage and management hub for modern multi-camera security systems. Engineered to support up to 4 wireless or wired IP cameras simultaneously, this powerful NVR enables true 24/7 continuous local recording. It features dual external high-gain antennas that establish a rock-solid, dedicated 2.4 GHz Wi-Fi network capable of penetrating walls and reaching a massive open-field wireless range of up to 100 meters, ensuring smooth, lag-free streaming from remote camera points.

Built for the next generation of high-definition surveillance, the X5S-4W supports ultra-high-resolution cameras up to 5MP/3K video quality. It is equipped with advanced H.265 video compression technology, which slashes required network bandwidth and shrinks video file sizes by up to 50% without compromising on crisp image quality. With a built-in SATA interface that handles large-capacity 3.5-inch hard drives up to 8TB, dual USB 2.0 ports for seamless backups, and full ONVIF/Hikvision protocol compatibility, this NVR delivers enthusiast-grade reliability and strict data protection for comprehensive home or business monitoring setups.

Feature Specification
Model Number CS-X5S-R100-4W (4-Channel Version)
Channel Capacity Supports up to 4 Wireless or Wired IP Cameras
Max. Video Resolution Up to 5MP / 3K Ultra-HD Preview & Playback
Wireless Infrastructure Dual External Antennas | 2.4 GHz Radio Frequency
Max Wireless Range Up to 100 Meters (300 Feet) in Open Fields
Video Encoding / Codec H.265 / H.264 High-Efficiency Video Compression
Video Outputs 1 × HDMI (Up to 2592×1444) | 1 × VGA (Up to 1920×1080)
Storage Interface 1 × Built-in SATA Port (Supports 3.5-inch HDDs from 1TB to 8TB)
Network & Interfaces 1 × 10/100M Adaptive Ethernet Port | 2 × USB 2.0 Ports
Open Protocols Native EZVIZ Protocol / Hikvision / ONVIF (V2.5 Compliance)
Power Supply DC 12V / 1.5A (Standby Power Consumption: ≤ 8W)
