Premium 12V Solderless DC Jack Wired Male and Female Pigtail Connectors for Professional CCTV Installations!
Keep your surveillance hardware running continuously and eliminate voltage drop errors with this high-conductivity DC Jack Wired connector series. Featuring a standard 5.5mm x 2.1mm heavy-duty molded barrel configuration, this set includes both Male pigtails for camera connections and Female jacks for power supply integrations. Built with heavy-duty stranded copper wires and wrapped in a flame-retardant industrial PVC jacket, the red and black color-coded leads ensure rapid, error-free splicing during large installations.
Interface Size: Universal 5.5mm x 2.1mm Power Barrel
Type Availability: High-Retention Male Plug and Female Jack Configurations
Polarity Layout: Color-Coded Red (+) and Black (-) wires for easy safety pairing
Core Performance: High-purity copper wiring minimizes resistance on 12V DC runs
Main Use: Seamless connection between security cameras, LED strips, and centralized power supplies
Pick up from the Micro CCTV Stores To pick up today
Free
Courier delivery Our courier will deliver to the specified address
2-3 Days
Delivery charges will vary based on the total weight of the items.
Transport Inform us of your preferred transport method to arrange the delivery.
Next Day
Free
Warranty 2 years Payment Methods:
When deploying commercial surveillance frameworks, establishing a stable low-voltage power path is highly critical.
The heavy-duty DC Jack Wired connection series delivers absolute electrical stability for installers across Sri Lanka.
Engineered with high-flexibility pre-stripped copper leads, this DC Jack Wired pigtail setup ensures safe 12V transmission runs.
Utilizing a premium DC Jack Wired terminal prevents common power loss issues, camera reboots, and nighttime IR failures.
To cross-reference international technical benchmarks for general low-voltage electrical hardware interfaces, feel free to visit the official educational portals of the American National Standards Institute (ANSI).
Modern security cameras require a continuous, noise-free electrical path to capture high-definition footage without pixel rolling.
Cheap, brittle wiring causes severe voltage drops over extended runs, risking damage to sensitive internal image sensors.
This heavy-duty DC Jack Wired model features a standard 5.5mm x 2.1mm barrel barrel shape built for maximum compatibility.
Whether you are wiring complex centralized power distribution boxes, this DC Jack Wired link simplifies on-site splicing tasks.
Every commercial installation crew should stock this dependable DC Jack Wired connector set to eliminate unexpected maintenance callbacks.
| Product Category | Low-Voltage DC Pigtail Power Connector |
| Core Keyword Tag | DC Jack Wired Premium Series |
| Connector Size Standard | 5.5mm Outer Diameter x 2.1mm Inner Pin Diameter |
| Available Variations | Male Plug Terminal / Female Jack Terminal |
| Wire Core Insulation | Pure Stranded Copper Matrix for High Current Flow |
| Jacket Material Framework | High-Tensile Flame-Retardant Industrial PVC Jacket |
| Operating Voltage Limits | Optimized for 12V DC (Supports up to 24V / 36V Low-Voltage Runs) |
| Main Application | CCTV Analog Cameras, LED Strip Lights, Central Power Supply Boxes |
When prepping your primary power delivery network lines, cleanly strip the outer casing to reveal the conductors safely.
Match the red wire of the DC Jack Wired plug directly to your positive line running from your centralized source.
Connect the black wire of the DC Jack Wired plug firmly onto the negative line to complete your circuit pathway.
Always insulate the exposed DC Jack Wired joints using professional heat-shrink tubing to prevent short circuits behind structures.
Q1: What is the primary difference between the Male and Female DC pigtails?
The Male DC Jack Wired plug plugs directly into the camera’s power port, while the Female jack is typically used to connect the adapter or power box end.
Q2: Is this low-voltage power pigtail cable weatherproof for outdoor use?
While the molded PVC structure handles regular moisture, you must completely seal the stripped wire joints using electrical tape for safe outdoor operation.
Q3: What current capacity can these stranded copper leads safely support?
This DC Jack Wired layout easily handles up to 2A to 5A continuous loads, making it ideal for standard security systems and LED accessories.
As a leading security hardware dealer in Sri Lanka, Micro CCTV takes proud ownership of supplying durable, verified structural supplies.
We screen our retail stock to eliminate thin, brittle steel wiring that causes connection failures, protecting your workflow reputation.
For large volume packs, bulk enterprise quotes, or nationwide retail delivery, contact our service desk using the official Micro CCTV Contact Portal to get your estimate processed today.
Ensure absolute power stability across your entire surveillance layout. Secure your premium DC Jack Wired packs today!
